| DIN 477 | Model No. | Product No. | Material | Nut | Nipple | Type | Washer |
|---|---|---|---|---|---|---|---|
| No.1 | SS-DIN477-1 | 200419110 | Stainless Steel | W21.8-14 (Left Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-1 | 200419111 | Brass | W21.8-14 (Left Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-1 | 200419112 | Brass/Chrome Plated | W21.8-14 (Left Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.2 | SS-DIN477-2 | 200419120 | Stainless Steel | W21.8-14 (Left Hand) | 2.5" Length (1/4"NPT) | A | Nylon |
| B-DIN477-2 | 200419121 | Brass | W21.8-14 (Left Hand) | 2.5" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-2 | 200419122 | Brass/Chrome Plated | W21.8-14 (Left Hand) | 2.5" Length (1/4"NPT) | A | Nylon | |
| No.3 | SS-DIN477-3 | 200419130 | Cast Steel | yoke | \ | D | \ |
| No.4 | SS-DIN477-4 | 200419140 | Stainless Steel | G3/8-19 (Left Hand) | 1-1/2" Length (1/8"NPT) | C | \ |
| B-DIN477-4 | 200419141 | Brass | G3/8-19 (Left Hand) | 1-1/2" Length (1/8"NPT) | C | \ | |
| BP-DIN477-4 | 200419142 | Brass/Chrome Plated | G3/8-19 (Left Hand) | 1-1/2" Length (1/8"NPT) | C | \ | |
| No.5 | SS-DIN477-5 | 200419150 | Stainless Steel | 1"-11 (Left Hand) | 2-1/2" Length (1/4"NPT) | A | Nylon |
| B-DIN477-5 | 200419151 | Brass | 1"-11 (Left Hand) | 2-1/2" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-5 | 200419152 | Brass/Chrome Plated | 1"-11 (Left Hand) | 2-1/2" Length (1/4"NPT) | A | Nylon | |
| No.6 | SS-DIN477-6 | 200419160 | Stainless Steel | W21.8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-6 | 200419161 | Brass | W21.8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-6 | 200419162 | Brass/Chrome Plated | W21.8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.7 | SS-DIN477-7 | 200419170 | Stainless Steel | G5/8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-7 | 200419171 | Brass | G5/8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-7 | 200419172 | Brass/Chrome Plated | G5/8-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.8 | SS-DIN477-8 | 200419180 | Stainless Steel | 1"-11 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-8 | 200419181 | Brass | 1"-11 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-8 | 200419182 | Brass/Chrome Plated | 1"-11 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.9 | SS-DIN477-9 | 200419190 | Stainless Steel | G3/4-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-9 | 200419191 | Brass | G3/4-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-9 | 200419192 | Brass/Chrome Plated | G3/4-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.10 | SS-DIN477-10 | 200419210 | Stainless Steel | W24.32-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon |
| B-DIN477-10 | 200419211 | Brass | W24.32-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-10 | 200419212 | Brass/Chrome Plated | W24.32-14 (Right Hand) | 2.35" Length (1/4"NPT) | A | Nylon | |
| No.11 | SS-DIN477-11 | 200419220 | Stainless Steel | G3/8-19 (Right Hand) | 1-1/2" Length (1/8"NPT) | A | Nylon |
| B-DIN477-11 | 200419221 | Brass | G3/8-19 (Right Hand) | 1-1/2" Length (1/8"NPT) | A | Nylon | |
| BP-DIN477-11 | 200419222 | Brass/Chrome Plated | G3/8-19 (Right Hand) | 1-1/2" Length (1/8"NPT) | A | Nylon | |
| No.12 | SS-DIN477-12 | 200419230 | Stainless Steel | G3/4-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon |
| B-DIN477-12 | 200419231 | Brass | G3/4-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon | |
| BP-DIN477-12 | 200419232 | Brass/Chrome Plated | G3/4-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon | |
| No.13 | SS-DIN477-13 | 200419240 | Stainless Steel | G5/8-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon |
| B-DIN477-13 | 200419241 | Brass | G5/8-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon | |
| BP-DIN477-13 | 200419242 | Brass/Chrome Plated | G5/8-14 (Right Hand) | 3" Length (1/4"NPT) | B | Nylon | |
| No.14 | SS-DIN477-14 | 200419250 | Stainless Steel | M19*1.5 (Left Hand) | 3" Length (1/4"NPT) | A | Nylon |
| B-DIN477-14 | 200419251 | Brass | M19*1.5 (Left Hand) | 3" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-14 | 200419252 | Brass/Chrome Plated | M19*1.5 (Left Hand) | 3" Length (1/4"NPT) | A | Nylon | |
| No.15 | SS-DIN477-15 | 200419260 | Stainless Steel | W21.8-14 (Left Hand) | 3" Length (1/4"NPT) | A | Nylon |
| B-DIN477-15 | 200419261 | Brass | W21.8-14 (Left Hand) | 3" Length (1/4"NPT) | A | Nylon | |
| BP-DIN477-15 | 200419262 | Brass/Chrome Plated | W21.8-14 (Left Hand) | 3" Length (1/4"NPT) |
