型号参数：
| T(管外径) |
型号 |
A |
Ax |
C |
D |
E |
F(六角尺寸) |
G(六角尺寸) |
H |
Hx |
壁孔尺寸 |
最大壁厚 |
| 英制 (in) |
|
in |
in |
in |
in |
in |
in |
in |
in |
in |
in |
in |
| 1/8 |
SS-BU-TF2 |
2.02 |
1.23 |
0.60 |
0.50 |
0.09 |
1/2 |
7/16 |
1.50 |
0.97 |
0.33 |
0.50 |
| 3/16* |
SS-BU-TF3 |
2.11 |
1.26 |
0.63 |
0.54 |
0.12 |
9/16 |
1/2 |
1.59 |
1.00 |
0.39 |
0.50 |
| 1/4 |
SS-BU-TF4 |
2.27 |
1.32 |
0.70 |
0.60 |
0.19 |
5/8 |
9/16 |
1.69 |
1.03 |
0.45 |
0.40 |
| 5/16* |
SS-BU-TF5 |
2.39 |
1.41 |
0.73 |
0.64 |
0.25 |
11/16 |
5/8 |
1.81 |
1.12 |
0.52 |
0.44 |
| 3/8 |
SS-BU-TF6 |
2.45 |
1.45 |
0.76 |
0.66 |
0.28 |
3/4 |
11/16 |
1.87 |
1.16 |
0.58 |
0.44 |
| 1/2 |
SS-BU-TF8 |
2.80 |
1.65 |
0.86 |
0.90 |
0.41 |
15/16 |
7/8 |
2.00 |
1.25 |
0.76 |
0.50 |
| 5/8* |
SS-BU-TF10 |
2.86 |
1.68 |
0.86 |
0.96 |
0.50 |
1-1/16 |
1 |
2.06 |
1.28 |
0.89 |
0.50 |
| 3/4 |
SS-BU-TF12 |
3.11 |
1.87 |
0.86 |
0.96 |
0.62 |
1-3/16 |
1-1/8 |
2.31 |
1.47 |
1.02 |
0.66 |
| 1 |
SS-BU-TF16 |
3.77 |
2.26 |
1.04 |
1.23 |
0.88 |
1-5/8 |
1-1/2 |
2.81 |
1.78 |
1.33 |
0.75 |
| 公制(mm) |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
| 3 |
SS-BU-TF3M |
51.3 |
31.2 |
15.3 |
12.9 |
2.4 |
14 |
12 |
38.1 |
24.6 |
8.30 |
12.7 |
| 6 |
SS-BU-TF6M |
57.7 |
33.6 |
17.7 |
15.3 |
4.8 |
16 |
14 |
42.9 |
26.2 |
11.5 |
10.2 |
| 8 |
SS-BU-TF8M |
61.0 |
36.1 |
18.6 |
16.2 |
6.4 |
18 |
16 |
46.0 |
28.6 |
13.1 |
11.2 |
| 10 |
SS-BU-TF10M |
63.7 |
37.0 |
19.5 |
17.2 |
7.9 |
22 |
19 |
48.5 |
29.4 |
16.3 |
11.2 |
| 12 |
SS-BU-TF12M |
71.0 |
41.9 |
22.0 |
22.8 |
9.5 |
24 |
22 |
50.8 |
31.8 |
19.5 |
