型号参数：
| T(管外径) |
型号 |
A |
C |
D |
F(六角尺寸) |
G (六角尺寸) |
H |
| 英制 (in) |
|
in |
in |
in |
in |
in |
in |
| 1/8 |
SS-C-TF2 |
0.79 |
0.60 |
0.50 |
7/16 |
7/16 |
0.53 |
| 3/16* |
SS-C-TF3 |
0.84 |
0.63 |
0.54 |
7/16 |
1/2 |
0.58 |
| 1/4 |
SS-C-TF4 |
0.92 |
0.70 |
0.60 |
1/2 |
9/16 |
0.62 |
| 5/16* |
SS-C-TF5 |
0.96 |
0.73 |
0.64 |
9/16 |
5/8 |
0.67 |
| 3/8 |
SS-C-TF6 |
1.01 |
0.76 |
0.66 |
5/8 |
11/16 |
0.72 |
| 1/2 |
SS-C-TF8 |
1.15 |
0.86 |
0.90 |
13/16 |
7/8 |
0.75 |
| 5/8* |
SS-C-TF10 |
1.18 |
0.86 |
0.96 |
15/16 |
1 |
0.78 |
| 3/4 |
SS-C-TF12 |
1.24 |
0.86 |
0.96 |
1-1/16 |
1-1/8 |
0.84 |
| 1 |
SS-C-TF16 |
1.51 |
1.04 |
1.23 |
1-3/8 |
1-1/2 |
1.03 |
| 公制 (mm) |
|
mm |
mm |
mm |
mm |
mm |
mm |
| 3 |
SS-C-TF3M |
20.1 |
15.3 |
12.9 |
12 |
12 |
13.5 |
| 6 |
SS-C-TF6M |
23.1 |
17.7 |
15.3 |
14 |
14 |
15.7 |
| 8 |
SS-C-TF8M |
24.5 |
18.6 |
16.2 |
15 |
16 |
17.0 |
| 10 |
SS-C-TF10M |
26.6 |
19.5 |
17.2 |
18 |
19 |
19.0 |
| 12 |
SS-C-TF12M |
29.1 |
22.0 |
22.8 |
22 |
