型号参数：
| T (管外径) |
P (NPT螺纹) |
型号 |
A |
B |
C |
D |
E |
F (六角尺寸) |
G (六角尺寸) |
H |
| 英制 ( in ) |
in |
|
in |
in |
in |
in |
in |
in |
in |
in |
| 1/8 |
1/8 |
SS-MC-TF2-NT2 |
1.20 |
0.38 |
0.60 |
0.50 |
0.09 |
7/16 |
7/16 |
0.94 |
| 1/8 |
1/4 |
SS-MC-TF2-NT4 |
1.40 |
0.56 |
0.60 |
0.50 |
0.09 |
9/16 |
7/16 |
1.14 |
| 3/16 |
1/8 |
SS-MC-TF3-NT2 |
1.23 |
0.38 |
0.63 |
0.54 |
0.12 |
7/16 |
1/2 |
0.97 |
| 3/16* |
1/4 |
SS-MC-TF3-NT4 |
1.43 |
0.56 |
0.63 |
0.54 |
0.12 |
9/16 |
1/2 |
1.17 |
| 1/4 |
1/8 |
SS-MC-TF4-NT2 |
1.29 |
0.38 |
0.70 |
0.60 |
0.19 |
1/2 |
9/16 |
1.00 |
| 1/4 |
1/4 |
SS-MC-TF4-NT4 |
1.49 |
0.56 |
0.70 |
0.60 |
0.19 |
9/16 |
9/16 |
1.20 |
| 1/4 |
3/8 |
SS-MC-TF4-NT6 |
1.51 |
0.56 |
0.70 |
0.60 |
0.19 |
11/16 |
9/16 |
1.22 |
| 1/4 |
1/2 |
SS-MC-TF4-NT8 |
1.76 |
0.75 |
0.70 |
0.60 |
0.19 |
7/8 |
9/16 |
1.47 |
| 5/16* |
1/8 |
SS-MC-TF5-NT2 |
1.34 |
0.38 |
0.73 |
0.64 |
0.19 |
9/16 |
5/8 |
1.05 |
| 5/16* |
1/4 |
SS-MC-TF5-NT4 |
1.52 |
0.56 |
0.73 |
0.64 |
0.25 |
9/16 |
5/8 |
1.23 |
| 3/8 |
1/8 |
SS-MC-TF6-NT2 |
1.39 |
0.38 |
0.76 |
0.66 |
0.19 |
5/8 |
11/16 |
1.10 |
| 3/8 |
1/4 |
SS-MC-TF6-NT4 |
1.57 |
0.56 |
0.76 |
0.66 |
0.28 |
5/8 |
11/16 |
1.28 |
| 3/8 |
3/8 |
SS-MC-TF6-NT6 |
1.57 |
0.56 |
0.76 |
0.66 |
0.28 |
11/16 |
11/16 |
1.28 |
| 3/8 |
1/2 |
SS-MC-TF6-NT8 |
1.82 |
0.75 |
0.76 |
0.66 |
0.28 |
7/8 |
11/16 |
1.53 |
| 3/8 |
3/4 |
SS-MC-TF6-NT12 |
1.88 |
0.75 |
0.76 |
0.66 |
0.28 |
1-1/16 |
11/16 |
1.59 |
| 1/2 |
1/8 |
SS-MC-TF8-NT2 |
1.53 |
0.38 |
0.86 |
0.90 |
0.19 |
13/16 |
7/8 |
1.13 |
| 1/2 |
1/4 |
SS-MC-TF8-NT4 |
1.71 |
0.56 |
0.86 |
0.90 |
0.28 |
13/16 |
7/8 |
1.31 |
| 1/2 |
3/8 |
SS-MC-TF8-NT6 |
1.71 |
0.56 |
0.86 |
0.90 |
0.38 |
13/16 |
7/8 |
1.31 |
| 1/2 |
1/2 |
SS-MC-TF8-NT8 |
1.93 |
0.75 |
0.86 |
0.90 |
0.41 |
7/8 |
7/8 |
1.53 |
| 1/2 |
3/4 |
SS-MC-TF8-NT12 |
1.99 |
0.75 |
0.86 |
0.90 |
0.41 |
1-1/16 |
7/8 |
1.59 |
| 1/2 |
1 |
SS-MC-TF8-NT16 |
2.25 |
0.94 |
0.86 |
0.90 |
0.41 |
1-3/8 |
7/8 |
1.85 |
| 5/8* |
3/8 |
SS-MC-TF10-NT6 |
1.74 |
0.56 |
0.86 |
0.96 |
0.38 |
15/16 |
1 |
1.34 |
| 5/8* |
1/2 |
SS-MC-TF10-NT8 |
1.93 |
0.75 |
0.86 |
0.96 |
0.47 |
15/16 |
1 |
1.53 |
| 5/8* |
3/4 |
SS-MC-TF10-NT12 |
1.99 |
0.75 |
0.86 |
0.96 |
0.50 |
1-1/16 |
1 |
1.59 |
| 3/4 |
1/2 |
SS-MC-TF12-NT8 |
1.99 |
0.75 |
0.86 |
0.96 |
0.47 |
1-1/16 |
1-1/8 |
1.59 |
| 3/4 |
3/4 |
SS-MC-TF12-NT12 |
1.99 |
0.75 |
0.86 |
0.96 |
0.62 |
1-1/16 |
1-1/8 |
1.59 |
| 3/4 |
1 |
SS-MC-TF12-NT16 |
2.25 |
0.94 |
0.86 |
0.96 |
0.62 |
1-3/8 |
1-1/8 |
1.85 |
| 1 |
3/4 |
SS-MC-TF16-NT12 |
2.26 |
0.75 |
1.04 |
1.23 |
0.62 |
1-3/8 |
1-1/2 |
1.78 |
| 1 |
1 |
SS-MC-TF16-NT16 |
2.45 |
0.94 |
1.04 |
1.23 |
0.88 |
1-3/8 |
1-1/2 |
1.97 |
| 公制 ( mm ) |
in |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
| 3 |
1/8 |
SS-MC-TF3M-NT2 |
30.5 |
9.70 |
15.3 |
12.9 |
2.4 |
12 |
12 |
23.9 |
| 3 |
1/4 |
SS-MC-TF3M-NT4 |
35.6 |
14.2 |
15.3 |
12.9 |
2.4 |
14 |
12 |
29.0 |
| 6 |
1/8 |
SS-MC-TF6M-NT2 |
32.8 |
9.70 |
17.7 |
15.3 |
4.8 |
14 |
14 |
25.4 |
| 6 |
1/4 |
SS-MC-TF6M-NT4 |
37.9 |
14.2 |
17.7 |
15.3 |
4.8 |
14 |
14 |
30.5 |
| 6 |
3/8 |
SS-MC-TF6M-NT6 |
38.4 |
14.2 |
17.7 |
15.3 |
4.8 |
18 |
14 |
31.0 |
| 6 |
1/2 |
SS-MC-TF6M-NT8 |
44.7 |
19.0 |
17.7 |
15.3 |
4.8 |
22 |
14 |
37.3 |
| 8 |
1/8 |
SS-MC-TF8M-NT2 |
34.2 |
9.70 |
18.6 |
16.2 |
4.8 |
15 |
16 |
26.7 |
| 8 |
1/4 |
SS-MC-TF8M-NT4 |
38.7 |
14.2 |
18.6 |
16.2 |
6.4 |
15 |
16 |
31.2 |
| 8 |
3/8 |
SS-MC-TF8M-NT6 |
39.3 |
14.2 |
18.6 |
16.2 |
6.4 |
18 |
16 |
31.8 |
| 8 |
1/2 |
SS-MC-TF8M-NT8 |
45.6 |
19.0 |
18.6 |
16.2 |
6.4 |
22 |
16 |
38.1 |
| 10 |
1/8 |
SS-MC-TF10M-NT2 |
36.3 |
9.70 |
19.5 |
17.2 |
4.8 |
18 |
19 |
28.7 |
| 10 |
1/4 |
SS-MC-TF10M-NT4 |
40.9 |
14.2 |
19.5 |
17.2 |
7.9 |
18 |
19 |
33.3 |
| 10 |
3/8 |
SS-MC-TF10M-NT6 |
40.9 |
14.2 |
19.5 |
17.2 |
7.9 |
18 |
19 |
33.3 |
| 10 |
1/2 |
SS-MC-TF10M-NT8 |
46.5 |
19.0 |
19.5 |
17.2 |
7.9 |
22 |
19 |
38.9 |
| 10 |
3/4 |
SS-MC-TF10M-NT12 |
48.0 |
19.0 |
19.5 |
17.2 |
7.9 |
27 |
19 |
40.4 |
| 12 |
1/8 |
SS-MC-TF12M-NT2 |
38.8 |
9.70 |
22.0 |
22.8 |
4.8 |
22 |
22 |
28.7 |
| 12 |
1/4 |
SS-MC-TF12M-NT4 |
43.4 |
14.2 |
22.0 |
22.8 |
7.1 |
22 |
22 |
33.3 |
| 12 |
3/8 |
SS-MC-TF12M-NT6 |
43.4 |
14.2 |
22.0 |
22.8 |
9.5 |
22 |
22 |
33.3 |
| 12 |
1/2 |
SS-MC-TF12M-NT8 |
49.0 |
19.0 |
22.0 |
22.8 |
9.5 |
22 |
22 |
38.9 |
| 12 |
3/4 |
SS-MC-TF12M-NT12 |
50.5 |
19.0 |
22.0 |
22.8 |
9.5 |
27 |
22 |
40.4 |
| 14 |
1/4 |
SS-MC-TF14M-NT4 |
44.1 |
14.2 |
22.0 |
24.4 |
7.1 |
24 |
25 |
34.0 |
| 14 |
3/8 |
SS-MC-TF14M-NT6 |
44.1 |
14.2 |
22.0 |
24.4 |
9.5 |
24 |
25 |
34.0 |
| 14 |
1/2 |
SS-MC-TF14M-NT8 |
49.0 |
19.0 |
22.0 |
24.4 |
11.1 |
24 |
25 |
38.0 |
| 16* |
3/8 |
SS-MC-TF16M-NT6 |
44.1 |
14.2 |
22.0 |
24.4 |
9.5 |
24 |
25 |
34.0 |
| 16* |
1/2 |
SS-MC-TF16M-NT8 |
49.0 |
19.0 |
22.0 |
24.4 |
11.9 |
24 |
25 |
38.9 |
| 16* |
3/4 |
SS-MC-TF16M-NT12 |
50.5 |
19.0 |
22.0 |
24.4 |
12.7 |
27 |
25 |
40.4 |
| 18* |
1/2 |
SS-MC-TF18M-NT8 |
50.5 |
19.0 |
22.0 |
24.4 |
11.9 |
27 |
30 |
40.4 |
| 18* |
3/4 |
SS-MC-TF18M-NT12 |
50.5 |
19.0 |
22.0 |
24.4 |
15.1 |
27 |
30 |
40.4 |
| 22* |
3/4 |
SS-MC-TF22M-NT12 |
52.3 |
19.0 |
22.0 |
26.0 |
15.9 |
30 |
32 |
42.2 |
| 22* |
1 |
SS-MC-TF22M-NT16 |
57.1 |
23.9 |
22.0 |
26.0 |
18.3 |
35 |
32 |
47.0 |
| 25* |
1/2 |
SS-MC-TF25M-NT8 |
57.5 |
19.0 |
26.5 |
31.3 |
11.9 |
35 |
38 |
45.2 |
| 25* |
3/4 |
SS-MC-TF25M-NT12 |
57.5 |
19.0 |
26.5 |
31.3 |
15.9 |
35 |
38 |
45.2 |
| 25* |
1 |
SS-MC-TF25M-NT16 |
62.3 |
12.9 |
26.5 |
31.3 |
21.8 |
35 |
38 |
50.0 |
| 注：无*的产品备有常规库存 |
有*的产品无常规库存 |
具体交货期需与公司联系 |
|
