Model parameters:
| T (Tube O.D.) |
Tx(Tube O.D.) |
Basic Ordering Number |
A |
C |
CX |
D |
Dx |
E |
F (Hex Flat) |
G (Hex Flat) |
Gx (Hex Flat) |
H |
| Fractional ( in ) |
in |
|
in |
in |
in |
in |
in |
in |
in |
in |
in |
in |
| 3/16* |
1/8 |
SS-RU-TF3-TF2 |
1.44 |
0.63 |
0.60 |
.054 |
0.50 |
0.09 |
7/16 |
1/2 |
7/16 |
0.92 |
| 1/4 |
1/5 |
SS-RU-TF4-TF2 |
1.52 |
0.70 |
0.60 |
0.60 |
0.50 |
0.09 |
1/2 |
9/16 |
7/16 |
0.97 |
| 1/4 |
1/8 |
SS-RU-TF4-TF3 |
1.55 |
0.70 |
0.63 |
0.60 |
0.54 |
0.12 |
1/2 |
9/16 |
1/2 |
1.00 |
| 5/16* |
1/8 |
SS-RU-TF5-TF2 |
0.56 |
0.73 |
0.60 |
0.64 |
0.50 |
0.09 |
9/16 |
5/8 |
7/16 |
1.02 |
| 5/16* |
1/4 |
SS-RU-TF5-TF4 |
1.66 |
0.73 |
0.70 |
0.64 |
0.60 |
0.19 |
9/16 |
5/8 |
9/16 |
1.08 |
| 3/8 |
1/8 |
SS-RU-TF6-TF2 |
0.76 |
0.76 |
0.60 |
0.66 |
0.50 |
0.09 |
5/8 |
11/16 |
7/16 |
1.06 |
| 3/8 |
1/4 |
SS-RU-TF6-TF4 |
1.61 |
0.76 |
0.70 |
0.66 |
0.60 |
0.19 |
5/8 |
11/16 |
9/16 |
1.12 |
| 3/8 |
5/16 |
SS-RU-TF6-TF5 |
1.74 |
0.76 |
0.73 |
0.66 |
0.64 |
0.25 |
5/8 |
11/16 |
5/8 |
1.16 |
| 1/2 |
1/8 |
SS-RU-TF8-TF2 |
1.78 |
0.86 |
0.60 |
0.90 |
0.50 |
0.09 |
13/16 |
7/8 |
7/16 |
1.12 |
| 1/2 |
1/4 |
SS-RU-TF8-TF4 |
1.85 |
0.86 |
0.70 |
0.90 |
0.19 |
0.09 |
13/16 |
7/8 |
9/16 |
1.16 |
| 1/2 |
3/8 |
SS-RU-TF8-TF6 |
1.91 |
0.86 |
0.76 |
0.90 |
0.66 |
0.28 |
13/16 |
7/8 |
11/16 |
1.22 |
| 5/8* |
3/8 |
SS-RU-TF10-TF6 |
1.94 |
0.86 |
0.76 |
0.96 |
0.66 |
0.28 |
15/16 |
1 |
11/16 |
1.25 |
| 5/8* |
1/2 |
SS-RU-TF10-TF8 |
2.05 |
0.86 |
0.86 |
0.96 |
0.90 |
0.41 |
15/16 |
1 |
7/8 |
1.25 |
| 3/4 |
1/4 |
SS-RU-TF12-TF4 |
1.94 |
0.86 |
0.70 |
0.96 |
0.60 |
0.19 |
1-1/16 |
1-1/8 |
9/16 |
1.25 |
| 3/4 |
3/8 |
SS-RU-TF12-TF6 |
2.00 |
0.86 |
0.76 |
0.96 |
0.66 |
0.28 |
1-1/16 |
1-1/8 |
11/16 |
1.31 |
| 3/4 |
1/2 |
SS-RU-TF12-TF8 |
2.11 |
0.86 |
0.86 |
0.96 |
0.90 |
0.41 |
1-1/16 |
1-1/8 |
7/8 |
1.31 |
| 3/4 |
5/8 |
SS-RU-TF12-TF10 |
2.11 |
0.86 |
0.86 |
0.96 |
0.96 |
0.50 |
1-1/16 |
1-1/8 |
1 |
1.31 |
| 1 |
1/2 |
SS-RU-TF16-TF8 |
2.38 |
1.04 |
0.86 |
1.23 |
0.90 |
0.41 |
1-3/8 |
1-1/2 |
7/8 |
1.61 |
| 1 |
3/4 |
SS-RU-TF16-TF12 |
2.38 |
1.04 |
0.86 |
1.23 |
0.96 |
0.62 |
1-3/8 |
1-1/2 |
1-1/8 |
1.59 |
| Metric ( mm ) |
mm |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
| 6 |
3 |
SS-RU-TF6M-TF3M |
38.6 |
17.7 |
15.3 |
15.3 |
12.9 |
2.4 |
14 |
14 |
12 |
24.6 |
| 8 |
6 |
SS-RU-TF8M-TF6M |
42.3 |
18.6 |
17.7 |
16.2 |
15.3 |
4.8 |
15 |
16 |
14 |
27.4 |
| 10 |
6 |
SS-RU-TF10M-TF6M |
44.5 |
19.5 |
17.7 |
17.2 |
15.3 |
4.8 |
18 |
19 |
14 |
29.5 |
| 10 |
8 |
SS-RU-TF10M-TF8M |
45.1 |
19.5 |
18.6 |
17.2 |
16.2 |
6.4 |
18 |
19 |
16 |
30.0 |
| 12 |
6 |
SS-RU-TF12M-TF6M |
47.0 |
22.0 |
17.7 |
22.8 |
15.3 |
4.8 |
22 |
22 |
14 |
29.5 |
| 12 |
8 |
SS-RU-TF12M-TF8M |
47.8 |
22.0 |
18.6 |
22.8 |
16.2 |
6.4 |
22 |
22 |
16 |
30.2 |
| 12 |
10 |
SS-RU-TF12M-TF10M |
48.7 |
22.0 |
19.5 |
22.8 |
17.2 |
7.9 |
22 |
