Model parameters:
| T (Tube O.D.) |
Tx (Tube O.D.) |
Basic Ordering Number |
A |
Ax |
D |
Dx |
E |
F (Hex Flat) |
| in |
in |
|
in |
in |
in |
in |
in |
in |
| 3/8 |
1/4 |
SS-RUT-TF6-TF4 |
2.40 |
1.14 |
0.66 |
0.60 |
0.19 |
5/8 |
| 1/2 |
1/4 |
SS-RUT-TF8-TF4 |
2.84 |
1.25 |
0.90 |
0.60 |
0.19 |
13/16 |
| 1/2 |
3/8 |
SS-RUT-TF8-TF6 |
2.84 |
1.31 |
0.90 |
0.66 |
0.28 |
13/16 |
| 5/8* |
3/8 |
SS-RUT-TF10-TF6 |
3.06 |
1.42 |
0.96 |
0.66 |
0.28 |
15/16 |
| 3/4 |
3/8 |
SS-RUT-TF12-TF6 |
3.14 |
1.46 |
0.96 |
0.66 |
0.28 |
1-1/8 |
| 3/4 |
1/2 |
SS-RUT-TF12-TF8 |
3.14 |
1.57 |
0.96 |
0.90 |
0.41 |
1-1/8 |
| 1 |
3/8 |
SS-RUT-TF16-TF6 |
3.86 |
1.65 |
1.23 |
0.66 |
0.28 |
1-3/8 |
| 1 |
1/2 |
SS-RUT-TF16-TF8 |
3.86 |
1.76 |
1.23 |
0.90 |
0.41 |
1-3/8 |
| 1 |
3/4 |
SS-RUT-TF16-TF12 |
3.86 |
1.76 |
1.23 |
0.96 |
0.62 |
