Model parameters:
| T (Tube O.D.) |
Basic Ordering Number |
A |
C |
D |
E |
F (Hex Flat) |
G (Hex Flax) |
H |
| Fractional ( in ) |
|
in |
in |
in |
in |
in |
in |
in |
| 1/8 |
SS-U-TF2 |
1.40 |
0.60 |
0.50 |
0.09 |
7/16 |
7/16 |
0.88 |
| 3/16* |
SS-U-TF3 |
1.47 |
0.63 |
0.54 |
0.12 |
7/16 |
1/2 |
0.95 |
| 1/4 |
SS-U-TF4 |
1.61 |
0.70 |
0.60 |
0.19 |
1/2 |
9/16 |
1.03 |
| 5/16* |
SS-U-TF5 |
1.69 |
0.73 |
0.64 |
0.25 |
9/16 |
5/8 |
1.11 |
| 3/8 |
SS-U-TF6 |
1.77 |
0.76 |
0.66 |
0.28 |
5/8 |
11/16 |
1.19 |
| 1/2 |
SS-U-TF8 |
2.02 |
0.86 |
0.90 |
0.41 |
13/16 |
7/8 |
1.22 |
| 5/8* |
SS-U-TF10 |
2.05 |
0.86 |
0.96 |
0.50 |
15/16 |
1 |
1.25 |
| 3/4 |
SS-U-TF12 |
2.11 |
0.86 |
0.96 |
0.62 |
1-1/16 |
1-1/8 |
1.31 |
| 1 |
SS-U-TF16 |
2.55 |
1.04 |
1.23 |
0.88 |
1-3/8 |
1-1/2 |
1.59 |
| Metric ( mm ) |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
| 3 |
SS-U-TF3M |
35.3 |
15.3 |
12.9 |
2.4 |
12 |
12 |
22.1 |
| 6 |
SS-U-TF6M |
41.0 |
17.7 |
15.3 |
4.8 |
14 |
14 |
26.2 |
| 8 |
SS-U-TF8M |
43.2 |
18.6 |
16.2 |
6.4 |
15 |
16 |
28.2 |
| 10 |
SS-U-TF10M |
46.2 |
19.5 |
17.2 |
7.9 |
18 |
19 |
31.0 |
| 12 |
SS-U-TF12M |
51.2 |
22.0 |
22.8 |
9.5 |
22 |
22 |
31.0 |
| 14 |
SS-U-TF14M |
52.0 |
22.0 |
24.4 |
11.1 |
24 |
25 |
31.8 |
| 16* |
SS-U-TF16M |
52.0 |
22.0 |
24.4 |
12.7 |
24 |
25 |
31.8 |
| 18* |
SS-U-TF18M |
53.5 |
22.0 |
24.4 |
15.1 |
27 |
30 |
33.3 |
| 22* |
SS-U-TF22M |
55.0 |
22.0 |
26.0 |
18.3 |
30 |
32 |
34.8 |
| 25* |
SS-U-TF25M |
65.0 |
26.5 |
31.3 |
21.8 |
35 |
