152L Series Station and Pipeline Regulators
Model 152L Series is designed for use with gas distribution systems in light flow applications, with a maximum inlet pressure of 350 PSIG, and is suitable for light flow application. Not for use on cylinders.
- Body and housing cap are machined from class "A" brass bar stock
- Single stage construction
- Stem type seat assembly for more reliable performance
- Delrin cap bushing for smooth adjustments
- 2" gauge for easy reading
- 2" diaphragm
- Weight: 2 lbs
- Conforms to CGA E-4 Standard for Gas Pressure Regulators
| MODEL # |
GAS SERVICE |
MAXIMUM INLET PRESSURE (PSI) |
MAXIMUM DELIVERY PRESSURE (PSI) |
INLET GAUGE |
OUTLET GAUGE |
INLET CONNECTION |
OUTLET CONNECTION |
| 152LF-80 |
L.P. Gas, Hydrogen |
350 |
4-80 |
None |
2", 100PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LX-80 |
Oxygen |
350 |
4-80 |
None |
2", 100PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LX-125 |
Oxygen |
350 |
5-125 |
None |
2", 200PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LX-200 |
Oxygen |
350 |
10-200 |
None |
2", 400PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LY-15 |
Acetylene |
350 |
2-15 |
None |
2", 30PSI, RL |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LIN-125 |
Inert Gas |
350 |
5-125 |
None |
2", 200PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
| 152LC-125 |
CO2, Air |
350 |
5-125 |
None |
2", 200PSI |
1/4" NPT(F) Port |
1/4" NPT(F) Port |
1 psi = 0.00689 MPa = 6.895 kPa = 0.06895 bar = 0.07 kgf / cm2,
1 SCFH = 0.0283 m3/h = 0.472 LPM
